the filling industrial pump can be used for filling the goaf of ferrous metal, non-ferrous metal, gold, chemical and other mines, concrete filling of the goaf and roadway of coal mines, long-distance and high lift transportation of sludge in sewage treatment plants, dredging of rivers and lakes, etc. the equipment is green and safe.
applicable solid content: it can pump tailings, fly ash, gangue, construction waste, fine stone and other mixed materials, with the concentration up to 85%.
一、相关参数
项目 |
指标与参数 |
型号 |
gbs1001-320 |
泵送物料 |
粉煤灰膏体、煤矸石膏体、尾矿膏体、赤泥、污水污泥等 |
含固率 |
粉煤灰膏体:55%~82% 煤矸石、尾矿膏体:70%~85% |
ph值 |
12 |
气体含量 |
< 1% |
颗粒物 |
£25 mm |
塌落度 |
15~28cm |
运行时间 |
£16h/d |
室内温度 |
05~40℃ |
理论排量m3/h |
97 |
泵送压力mpa |
15 |
正常泵送压力mpa |
10 |
输送缸内径mm |
300 |
输送缸行程mm |
2100 |
换向形式 |
s管阀 |
泵出口通径mm |
150 |
电动机额定功率kw |
2×160 |
电动机额定电压v |
380 |
工作装置外形尺寸mm |
7500×1300×1445 |
工作装置大约重量kg |
8500 |
动力部分外形尺寸mm |
4000×2000×2100 |
动力部分大约重量kg |
7000 |
2、 performance and features
1. hydraulic control reversing and electric proportional control of main oil pump are adopted to ensure safe and reliable pumping;
2. it has high and low pressure automatic switching function, which can meet the requirements of different working conditions;
3. equipped with electric proportional buffering technology and hydraulic buffering technology, the pumping mechanism operates stably with small impact;
4. the combination of two pump hydraulic system and two power units, constant power control, further improve the versatility and reliability;
5. automatic withdrawal of double pistons, one key can easily realize the return of two concrete pistons to the water tank, and the maintenance is faster;
6. forced feeding by high-power mixing motor can also mix normally without being stuck and improve the suction performance in case of material difference;
7. split design, flexible installation and layout, strong adaptability and convenient maintenance;
8. special variable energy saving technology, energy saving;
9. wearing parts have high wear resistance, long service life and convenient disassembly and assembly.
