the hoists produced by our company are mainly divided into th, td and ne models.
1、 th type et elevator is a product developed by our company based on the experience of many companies. its main performance and parameters conform to jb / t3926-1999 < vertical et elevator > > and the ring chain for traction conforms to mt36-80 high strength ring chain for mining.
th type elevator has the following characteristics:
1. compared with hl type, th type with the same et width increased the conveying capacity by nearly one time;
2. the lower part adopts the heavy hammer lever type tension device, which can realize the automatic tension. after one time installation, it does not need to be adjusted for a long time, and can maintain a constant tension force, so as to ensure the normal operation of the machine and avoid slipping and chain falling off;
3. the puller is a high strength ring chain made of low alloy steel. after proper heat treatment, it has high tensile strength, wear resistance and long service life;
4. the elevator is a mixture or gravity unloading, take-off loading, suitable for conveying powder, granular, small pieces of low abrasive materials with a stacking density of not more than 1.5t/m3, and the material temperature is not more than 250 ℃;
5. this machine has two kinds of hoppers:
zh type (medium deep hopper) is generally suitable for conveying wet, caking and hard to throw materials, such as wet sand and molding sand. chemical fertilizer, alkali powder, etc.
sh type (deep et) is generally suitable for conveying dry, loose and easy to throw materials, such as cement, gravel, mud, etc.
2、 td type et elevator is a new product of d type. its main technical performance parameters refer to international standards and foreign advanced standards.
its main characteristics are: large conveying capacity, stable and reliable operation, fast speed, high lifting height, good sealing, so as to expand the scope of use. it can meet the transportation requirements of building materials, machinery, power, chemical and other departments.
td series et elevator adopts two ways of discharging: centrifugal type and mixed type. it is suitable for conveying non abrasive and semi abrasive materials, such as grain, coal, cement, sandstone, chemical fertilizer, etc. with a bulk density of no more than 1.5t/m3. td material temperature is generally not more than 60 ℃.
there are many models of td et elevator, and four models of td250, td315, td400 and td500 are commonly used in the production of fly ash comprehensive utilization industry.
3、 ne elevator is a widely used vertical lifting equipment, which is used to lift various materials, such as ore, coal, gypsum, cement and cement clinker.
the ne series plate chain elevator of our company has four models commonly used in the industry of comprehensive utilization of fly ash: ne15, ne30, ne50, ne100, which mainly has the following characteristics:
1. the scope of promotion is wide.
2. large conveying capacity.
3. low driving power.
4. long service life.
5. lifting height is high.
6. good sealing and less environmental pollution.
7. good operation reliability.
8. it is easy to operate and maintain, with few wearing parts.
9. small mechanical size.
10. high structural accuracy.
11. low use cost.
